Lexus ES XV40 facelift (2009-2012) +stp wrn Wiring diagram
This page shows the only wiring diagram for the component.+stp wrn, which is found in the car Lexus ES XV40 facelift (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram +stp wrn (1 of 1)
+B (DOME) IG+
+STP WRN
2 9 3 5 8 7 4 11 -STP -TR +T -TL
ASSEMBLY
BLK WIRE
BLK/ WHT WIRE
BLU WIRE
BRN WIRE
CAN I/F
CANADA
CENTER STOP LAMP
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DCTY
DRIVE IC
ECU-IG 2 FUSE
FUSE
GRN WIRE
GRY WIRE
HEAD
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED ECU-
INSTRUMENT PANEL J/B
J/B 3 (LEFT SIDE OF DASH)
J/B 4 (RIGHT SIDE OF DASH)
LAMP FAILURE INDICATOR SENSOR (LEFT REAR HEADLIGHT ASSEMBLY)
LCTY
LEFT FRONT SIDE MARKER LAMP
LEFT HEADLAMP ASSEMBLY
LEFT TURN IND
LGCY
MAIN BODY ECU
MICRO COMPUTER
NOISE FILTER (STOP LAMP) (BASE OF LEFT "C" PILLAR)
ORG/ WIRE
PARKING
PCTY
PNK WIRE
POWER SUPPLY CIRCUIT
RCTY
REAR LIGHTS IND
RED WIRE
RELAY ENERGIZED
RELAY ENERGIZED ECU IG 1 FUSE
RIGHT FRONT SIDE MARKER LAMP
RIGHT HEADLAMP
RIGHT TURN IND
RR FOG/ BRK RELAY
STOP FUSE
TAIL
TAIL FUSE
TAIL IND
TAIL RELAY
WHT WIRE
WHT/ BLK WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> +STP WRN
