Lexus ES XV40 facelift (2009-2012) sbr shrl pnk Wiring diagram
This page shows the only wiring diagram for the component.sbr shrl pnk, which is found in the car Lexus ES XV40 facelift (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sbr shrl pnk (1 of 1)
AFS OFF
AFS OFF SWITCH
AUTO HEAD
BLK WIRE
BLU WIRE
BRN WIRE
CAN I/F
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR 3 (UNDER LEFT SIDE OF DASH)
ECU-IG 2 FUSE
ENGINE ROOM J/B
GAUGE 2 FUSE
GRN WIRE
GRY WIRE
H-LP LVL FUSE
HEAD
HEADLAMP DIMMER SWITCH ASSEMBLY
HEADLAMP SWIVEL ECU (LEFT SIDE OF DASH)
HOT AT ALL TIMES
HOT IN ON OR START
IGS IG
INDICATOR DRIVE IC
INIT
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
J/B 3 (LEFT SIDE OF DASH)
J/B 4 (RIGHT SIDE OF DASH)
LEFT HEADLAMP ASSEMBLY
LEFT HEADLAMP LEVELING MOTOR (LEFT HEADLIGHT ASSEMBLY)
LH E
LH- RH- SML LH+
LHM+
LT BLU WIRE
LT GRN WIRE
LVL
MAIN BODY ECU (LEFT SIDE OF DASH)
MICRO COMPUTER
MPX-B FUSE
MSW
OFF LIGHT CONTROL SWITCH
ORG/ WIRE
PNK SMGR RIGHT HEADLAMP ASSEMBLY WIRE
POWER SUPPLY CIRCUIT
RED WIRE
RH E RIGHT HEADLAMP LEVELING MOTOR (RIGHT HEADLIGHT ASSEMBLY)
RHM +
SBR SHRL PNK WIRE
SGR
SHB
SHG HEIGHT CONTROL SENSOR (CENTER REAR OF VEHICLE)
SHRR
SMBL
SMBR
SMGL
SMGL SMGR PNK WIRE
SML
SMR
SMR RH+
TAIL
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Adaptive front lighting circuit -> SBR SHRL PNK WIRE
