Lexus ES XV40 facelift (2009-2012) off hock Wiring diagrams
This page contains all the electrical diagrams for the component. off hock, in which he is found in the car Lexus ES XV40 facelift (2009-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram off hock (1 of 3)
-TW
1 2 3 4 5 6 +B GND
1 2 3 4 5 6 7 8 9 10 11 12 SL+ SR+ WFL+ RL+ RR+ SL- SR- WFL- WFR- WFR+ RL- RR-
14 SPEAKER
AMP 2 FUSE
AMP FUSE
BLK WIRE
BLU WIRE
BRN WIRE
CENTER SPEAKER
CTR- CTR+ FL- MR-
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER SYSTEM
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LEFT FRONT DOOR SPEAKER
LEFT INSTRUMENT PANEL SPEAKER (W/ 14 SPEAKER)
LEFT INSTRUMENT PANEL TWEETER
LEFT REAR DOOR SPEAKER
LEFT REAR DOOR TWEETER
LEFT STEERING SWITCH
LT BLU WIRE
LT GRN WIRE
MI- SLDO MO-
MODE
OFF HOCK
ON HOCK
ORG/ WIRE
PNK FL+ MR+ WIRE
PNK WIRE
RED WIRE
RIGHT REAR DOOR SPEAKER
RIGHT REAR DOOR TWEETER
RIGHT STEERING SWITCH
SEEK
SPD WUI MI+ SLDI MO+
SPEAKER (WOOFER)
SPIRAL CABLE (LEFT SIDE OF DASH)
STEERING PAD SWITCH
STEREO COMPONENT AMPLIFIER (RIGHT SIDE OF TRUNK)
TWL-
VIO WIRE
VOICE
VOL (-)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Navigation circuit (4 of 4) -> OFF HOCK
Wiring diagram off hock (2 of 3)
-TW
1 2 3 4 5 6 +B GND
1 2 3 4 5 6 7 8 9 10 11 12 SL+ SR+ WFL+ RL+ RR+ SL- SR- WFL- WFR- WFR+ RL- RR-
14 SPEAKER
AMP 2 FUSE
AMP FUSE
BLK WIRE
BLU WIRE
BRN WIRE
CENTER SPEAKER
CTR- CTR+ FL- MR-
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER SYSTEM
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LEFT FRONT DOOR SPEAKER
LEFT INSTRUMENT PANEL SPEAKER (W/ 14 SPEAKER)
LEFT INSTRUMENT PANEL TWEETER
LEFT REAR DOOR SPEAKER
LEFT REAR DOOR TWEETER
LEFT STEERING SWITCH
LT BLU WIRE
LT GRN WIRE
MI- SLDO MO-
MODE
OFF HOCK
ON HOCK
ORG/ WIRE
PNK FL+ MR+ WIRE
PNK WIRE
RED WIRE
RIGHT REAR DOOR SPEAKER
RIGHT REAR DOOR TWEETER
RIGHT STEERING SWITCH
SEEK
SPD WUI MI+ SLDI MO+
SPEAKER (WOOFER)
SPIRAL CABLE (LEFT SIDE OF DASH)
STEERING PAD SWITCH
STEREO COMPONENT AMPLIFIER (RIGHT SIDE OF TRUNK)
TWL-
VIO WIRE
VOICE
VOL (-)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Radio circuit, with navigation (4 of 4) -> OFF HOCK
Wiring diagram off hock (3 of 3)
AMP 2 FUSE
BLK WIRE
BLU WIRE
BRN WIRE
CENTER SPEAKER
CTR- CTR+
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
FL- FR- FR+ RL- RR-
GRN WIRE
HOT AT ALL TIMES
J/B 4 (RIGHT SIDE OF DASH)
LEFT FRONT DOOR SPEAKER
LEFT INSTRUMENT PANEL TWEETER
LEFT REAR DOOR SPEAKER
LEFT STEERING SWITCH
LT GRN WIRE
MODE
OFF HOCK
ON HOCK
ORG/ WIRE
PNK FL+ RL+ RR+ WIRE
PNK WIRE
RED WIRE
RIGHT REAR DOOR SPEAKER
RIGHT STEERING SWITCH
SEEK
SPEAKER (WOOFER)
SPIRAL CABLE (LEFT SIDE OF DASH)
STEERING PAD SWITCH
STEREO COMPONENT AMPLIFIER (RIGHT SIDE OF TRUNK)
TWL-
VIO WIRE
VOICE
VOL (-)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Radio circuit, without navigation (3 of 3) -> OFF HOCK
