Lexus ES XV40 facelift (2009-2012) head auto Wiring diagram
This page shows the only wiring diagram for the component.head auto, which is found in the car Lexus ES XV40 facelift (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram head auto (1 of 1)
21 7 25 17 28 18 19 20 PCTY RCTY LGCY HEAD FFOG CLTE CLTS CLTB
24 4 13 21 23 DCTY FFGO HF
6 5 4 3 2 1 CLTB CLTS
8 11 HRLY DRL
AUTOMATIC LIGHT CONTROL SENSOR (CENTER OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
CLTE
COMPUTER DATA LINES SYSTEM
DIMMER SWITCH
DOOR 2 FUSE
ECU- IG 1 FUSE
ECU-ACC FUSE
FOG LIGHT SWITCH
FOG RELAY
FR FOG FUSE
FRONT TAIL OFF
GRN WIRE
GRY WIRE
HEAD AUTO
HEAD TAIL OFF AUTO
HEADLAMP DIMMER SWITCH ASSEMBLY
HIGH HIGH FLASH FLASH
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START
IG BATB TRLY
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
J/B 3 (LEFT SIDE OF DASH)
LCTY
LEFT FRONT FOG LIGHT
LIGHT CONTROL SWITCH
LT GRN WIRE
MAIN BODY ECU (LEFT SIDE OF DASH)
OFF
PARKING BRAKE SWITCH (LEFT SIDE OF DASH)
PNK WIRE
RED WIRE
RIGHT FRONT FOG LIGHT
TAIL
TAIL FUSE
TAIL RELAY
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Headlamps circuit (1 of 2) -> HEAD AUTO
