Lexus ES XV40 facelift (2009-2012) down front Wiring diagram
This page shows the only wiring diagram for the component.down front, which is found in the car Lexus ES XV40 facelift (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram down front (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
DOWN
DOWN FRONT
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
FDWN RCLF
FRONT
FRONT VERTICAL SLDR FUP
GRN WIRE
HOT AT ALL TIMES
LIFTER
LT BLU WIRE
P-P/SEAT FUSE
PNK WIRE
POWER SEAT MOTOR (RIGHT FRONT SEAT FRONT VERTICAL CONTROL) (RIGHT FRONT SEAT)
POWER SEAT MOTOR (RIGHT FRONT SEAT LIFTER CONTROL) (BASE OF RIGHT FRONT SEAT)
POWER SEAT MOTOR (RIGHT FRONT SEAT LUMBAR SUPPORT CONTROL)
POWER SEAT MOTOR (RIGHT FRONT SEAT RECLINING CONTROL) (BASE RIGHT FRONT SEAT)
POWER SEAT MOTOR (RIGHT FRONT SEAT SLIDE CONTROL) (BASE OF RIGHT FRONT SEAT)
POWER SEAT SWITCH (RIGHT FRONT SEAT LUMBAR SUPPORT CONTROL)
POWER SEAT SWITCH (RIGHT FRONT SEAT)
RCLR RUP
RDWN
REAR UP
RECLINING
SLDF
SLIDE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Passenger power seat circuit -> DOWN FRONT
