Pre-collision circuit for Lexus ES XV40 (2006-2009)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 MOR+ MOL+ B+ MOR- MOL- BLK WIRE BLU WIRE BRN WIRE CANL SIL COMPUTER DATA LINES SYSTEM ECU-IG 2 FUSE ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) J/B 4 (RIGHT SIDE OF DASH) JUNCTION LEFT FRONT SEAT OUTER BELT MOTOR (NEAR LEFT "B" PILLAR) PSB FUSE RED WIRE RIGHT FRONT SEAT OUTER BELT MOTOR (NEAR RIGHT "B" PILLAR) SEAT BELT CONTROL ECU (NEAR BASE OF "C" PILLAR) WHT WIRE WHT/BLK WIRE YEL WIRE
