Electrochromic mirror circuit for Lexus ES XV40 (2006-2009)

1 2 3 4 5 PNK EC- EC+ IG WIRE BLK WIRE BLU WIRE BRN WIRE ECU- IG 1 FUSE HOT IN ON OR START INNER REAR VIEW MIRROR INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) J/B 3 (LEFT SIDE OF DASH) LEFT OUTER REAR VIEW MIRROR LT GRN WIRE OVERHEAD J/B (CENTER FRONT OF ROOF) PNK WIRE RIGHT OUTER REAR VIEW MIRROR WHT/BLK WIRE
