Car Wiring Diagrams for Passive restraints circuit for Lexus ES XV40 (2006-2009)

BLK WIRE BUCKLE SWITCH HOT IN ON OR START ECU- IG 1 FUSE INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) J/B 3 (LEFT SIDE OF DASH) J/B 4 (RIGHT SIDE OF DASH) J/C LEFT "C" PILLAR) LEFT FRONT SEAT INNER BELT LEFT FRONT SEAT OUTER BELT (LEFT "B" PILLAR) ORG/ WIRE REDUCER TENSION RIGHT FRONT SEAT INNER BELT RIGHT FRONT SEAT OUTER BELT (RIGHT "B" PILLAR) TENSION REDUCER WHT/BLK WIRE
