Rear defogger & heated mirrors circuit for Lexus ES XV40 (2006-2009)

Rear defogger & heated mirrors circuit

Get access

A/C 2 FUSE A/C AMPLIFIER (RIGHT SIDE OF DASH) BLK WIRE BRN WIRE FUSE GRN WIRE HOT AT ALL TIMES ENGINE ROOM R/B (LEFT SIDE OF ENGINE RR DEF FUSE COMPT) HOT IN ON OR START INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) J/B 3 (LEFT SIDE OF DASH) LEFT OUTER REAR VIEW MIRROR MIRROR HEATER MIR HTR NOISE FILTER (REAR WINDOW DEFOGGER) (NEAR LEFT ``C" PILLAR) PNK WIRE RDFG REAR WINDOW DEFOGGER RED WIRE RIGHT OUTER REAR VIEW MIRROR MIRROR HEATER RR DEF RELAY VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
