Lexus ES XV40 (2006-2009) side marker turn tail Wiring diagram
This page shows the only wiring diagram for the component.side marker turn tail, which is found in the car Lexus ES XV40 (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram side marker turn tail (1 of 1)
A/C CONTROL ASSEMBLY (W/O LEXUS NAVIGATION SYSTEM) (CENTER OF DASH)
AUTO HEAD
BACK- UP BACK- UP TAIL
BACK-UP LAMPS CIRCUIT BACK-UP LAMPS CIRCUIT
BLK WIRE
BLK/ WHT WIRE
BLU WIRE
BRN WIRE
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPARTMENT)
GAUGE 1 FUSE
GAUGE 2 FUSE
GRN WIRE
HAZ FUSE
HAZARD SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
J/B 3 (LEFT SIDE OF DASH)
J/B 4 (RIGHT SIDE OF DASH)
LEFT FRONT TURN SIGNAL LAMP
LEFT LICENSE PLATE LAMP
LEFT REAR COMBINATION LAMP
MULTI-DISPLAY (W/ LEXUS NAVIGATION SYSTEM)
OFF LIGHT CONTROL SWITCH HEADLAMP DIMMER SWITCH ASSEMBLY
RED WIRE
RIGHT FRONT TURN SIGNAL LAMP
RIGHT LICENSE PLATE LAMP
RIGHT REAR COMBINATION LAMP
SIDE MARKER
SIDE MARKER TURN TAIL
STOP
TAIL
TAIL OFF AUTO HEAD TAIL
TURN
TURN SIGNAL SWITCH
W/ SIDE MARKER
W/O REAR FOG LIGHT
W/O REAR FOG LIGHT W/ REAR FOG LIGHT
WHT WIRE
WHT/ BLK WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> SIDE MARKER TURN TAIL
