Lexus ES XV40 (2006-2009) right front map lamp Wiring diagram
This page shows the only wiring diagram for the component.right front map lamp, which is found in the car Lexus ES XV40 (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front map lamp (1 of 1)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
COURTESY
DIODE (INTERIOR LIGHT) (RIGHT SIDE OF DASH)
DIODE (LEFT REAR DOOR COURTESY) (NEAR LEFT REAR DOOR COURTESY SWITCH)
DIODE (LUGGAGE COMPARTMENT LAMP)
DIODE (RIGHT REAR DOOR COURTESY) (NEAR RIGHT REAR DOOR COURTESY SWITCH)
DOOR
FOOT LAMP
FRONT ROOM LAMP IND
GRY WIRE
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
J/B 3 (LEFT SIDE OF DASH)
LEFT
LEFT FRONT MAP LAMP
LEFT FRONT MAP LAMP SWITCH
LEFT REAR DOOR COURTESY LAMP
LEFT REAR DOOR COURTESY SWITCH (LEFT "C" PILLAR)
LEFT REAR MAP LAMP
LUGGAGE COMPARTMENT LAMP
LUGGAGE DOOR LOCK ASSEMBLY (AT TRUNK LOCK ASSEMBLY)
MAP LAMP RIGHT FRONT
NOISE FILTER (DOME LAMP) (NEAR LEFT "C" PILLAR)
OFF
OVERHEAD J/B (CENTER FRONT OF ROOF)
REAR ROOM LAMP
RED WIRE
RIGHT
RIGHT FRONT MAP LAMP
RIGHT OUTER REAR VIEW MIRROR
RIGHT REAR DOOR COURTESY LAMP
RIGHT REAR DOOR COURTESY SWITCH (RIGHT "C" PILLAR)
RIGHT REAR MAP LAMP
SWITCH
VIO WIRE
W/ MAP LAMP
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> RIGHT FRONT MAP LAMP
