Wiper/washer circuit, without auto wiper system for Lexus ES XV30 facelift (2003-2006)
Wiper/washer circuit, without auto wiper system
BLK WIRE
BLU WIRE
COMBINATION METER
COMBINATION SWITCH
DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH) WIPER FUSE
EB (AT RIGHT FENDER)
ED (AT LEFT FENDER)
FRONT WASHER SWITCH
FRONT WIPER MOTOR (ON LEFT SIDE OF FIREWALL)
FRONT WIPER SWITCH
GAUGE 1 FUSE
HOT IN ON OR START
IB (AT DASH BRACE, LEFT SIDE)
INT TIME
J/C 4
OFF
ORG/ WIRE
PASSENGER SIDE J/B (BEHIND RIGHT SIDE OF DASH)
PNK WIRE
PNK/BLU WIRE
SOLID STATE
WASHER FUSE
WASHER LEVEL IND
WASHER MOTOR (AT RIGHT FRONT CORNER OF ENGINE COMPT)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
