Electrochromic mirror circuit for Lexus ES XV30 facelift (2003-2006)
Electrochromic mirror circuit
BLK WIRE
BLU WIRE
DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH)
EC+
GAUGE 2 FUSE
GRY WIRE
HOT IN ON OR START
IA (AT DASH REINFORCEMENT, LEFT SIDE)
INNER MIRROR, COMPASS
J/C 10 (BEHIND LOWER RIGHT SIDE OF DASH)
J/C 5 (BEHIND UPPER LEFT SIDE OF DASH)
LEFT REMOTE CONTROL MIRROR EC-
LT GRN WIRE
LT GRN/BLK WIRE
OVERHEAD J/B (MOON ROOF) (ON FRONT CENTER OF ROOF)
RED WIRE
RED/BLU WIRE
RIGHT REMOTE CONTROL MIRROR EC-
W/ MOON- ROOF
W/O MOON- ROOF
W/O MOON- ROOF W/ MOON- ROOF
WHT WIRE
WHT/BLK WIRE
