Lexus ES XV30 facelift (2003-2006) sgnd th Wiring diagram
This page shows the only wiring diagram for the component.sgnd th, which is found in the car Lexus ES XV30 facelift (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sgnd th (1 of 1)
1 2 3 4 TH SGND
A/C CONTROL ASSEMBLY (BEHIND CENTER OF DASH)
BA (UNDER
BB (UNDER FRONT
BLK WIRE
BLK/BLU WIRE
BLU WIRE
DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH)
DRIVER'S SEAT
GRN WIRE
HOT IN ON OR START
J/C 20, 21 (BELOW RIGHT FRONT SEAT)
LEFT SEAT HEATER (IN LEFT FRONT SEAT)
LT GRN WIRE
LT GRN/BLK WIRE
PASSENGER'S SEAT)
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
SEAT HTR FUSE
SGND TH
SHD
SHDE SHDT
SHP+
SHP- SHPE
SHPT
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Heated seats circuit -> SGND TH
