Lexus ES XV30 facelift (2003-2006) front fog indicator Wiring diagram

11 10 ON FOGLIGHT SWITCH 13 12 HEAD ALTL AUTO GND HU HF AUTO OFF TAIL AUTOMATIC LIGHT CONTROL SENSOR (ON TOP LEFT SIDE OF DASH) BLK WIRE BLU WIRE BODY ECU BRN WIRE CLTS CLTE CLTB COMBINATION METER DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH) EB (AT RIGHT FENDER) EC (AT LEFT FENDER) ECU-ACC FUSE ECU-B FUSE ECU-IG FUSE FLASH DIMMER SWITCH FLASH LOW FOG FUSE FOG RELAY FRONT FOG INDICATOR GRN WIRE GRN/RED WIRE GRY WIRE HEAD HEAD INDICATOR (USA) HEAD RELAY HIGH BEAM INDICATOR HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START IA (AT DASH REINFORCEMENT, LEFT SIDE) IB (AT DASH BRACE, LEFT SIDE) ID (AT DASH BRACE, RIGHT SIDE) JUNCTION CONNECTOR 4 COMBINATION SWITCH JUNCTION CONNECTOR 8, 9 (BEHIND UPPER RIGHT SIDE OF DASH) LEFT FRONT DOOR COURTESY SWITCH (ON LEFT "B" PILLAR) LEFT FRONT FOG LIGHT LIGHT CONTROL SWITCH LOW HIGH LT BLU WIRE MAIN FUSE OFF PARKING BRAKE SWITCH (BEHIND LEFT SIDE OF DASH) PASSENGER SIDE J/B (BEHIND RIGHT SIDE OF DASH) PKB TAIL HEAD PNK WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE SDRL DCTY DRL SGND SIG STARTING/ CHARGING SYSTEM TAIL RELAY USA VIO WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE YEL WIRE
