Car Wiring Diagrams for Heated seats circuit for Lexus ES XV30 (2001-2003)

A/C CONTROL ASSEMBLY BA (UNDER FRONT PASSENGER'S SEAT) BB (UNDER FRONT PASSENGER'S SEAT) BLK WIRE BLK/BLU WIRE BLU WIRE DRIVERS SIDE J/B (BEHIND LEFT SIDE OF DASH) HOT IN ON OR START LEFT SEAT HEATER TH SGND LT GRN WIRE LT GRN/BLK WIRE RED/BLK WIRE RED/YEL WIRE RIGHT SEAT HEATER SGND TH SEAT HTR FUSE SHD SHDT SHDE SHP+ SHP- SHPE SHPT WHT/BLK WIRE
