Lexus ES XV30 (2001-2003) vupl esl Wiring diagram
This page shows the only wiring diagram for the component.vupl esl, which is found in the car Lexus ES XV30 (2001-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vupl esl (1 of 1)
+SR -SR
-SL +SL
A/C CONTROL ASSEMBLY
BA (UNDER FRONT PASSENGER'S SEAT)
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
COMBINATION METER
DATA LINK CONNECTOR 3 (PARTIAL) (AT LOWER LEFT SIDE OF DASH)
DRIVER SIDE J/B (AT LEFT KICK PANEL)
DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH)
GAUGE 1 FUSE
GRN WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
HOT IN ON OR START
HTR FUSE
ID (RIGHT DASH BRACE)
LEFT FRONT AIR BAG SENSOR (ON LEFT FRONT OF ENGINE COMPARTMENT)
LT GRN/BLK WIRE
PASSENGER SIDE J/B (BEHIND RIGHT SIDE OF DASH)
PASSENGER SIDE J/B (RIGHT SIDE OF DASH)
PBEW
PNK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
RED WIRE
RIGHT FRONT AIR BAG SENSOR (ON RIGHT FRONT OF ENGINE COMPARTMENT)
SEAT POSITION AIR BAG SENSOR
SOLID STATE
SRS
VUPL ESL
W/ VSC
W/O VSC
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/PNK WIRE
YEL/RED WIRE
Go to component -> Supplemental restraint circuit (2 of 2) -> VUPL ESL
