Lexus ES XV30 (2001-2003) tam tpi Wiring diagram

+B IG AMDH AMDC AMPH AMPC AOF AOD AIF AIR GND 1 2 TSL TSR A/C AMBIENT TEMPERATURE SENSOR (LEFT CENTER OF FRONT BUMPER) A/C CONTROL ASSEMBLY (BEHIND CENTER OF DASH) A/C ROOM TEMPERATURE SENSOR (CENTER OF DASH) A/C SOLAR SENSOR (TOP LEFT SIDE OF DASH) A/C THERMISTOR (RIGHT SIDE OF DASH) A/CI ACS AIR INLET CONTROL SERVO MOTOR (RIGHT SIDE OF DASH) AIR MIX CONTROL SERVO MOTOR (DRIVER) (LOWER LEFT CENTER OF DASH) AIR MIX CONTROL SERVO MOTOR (PASSENGER) (RIGHT CENTER OF DASH) AIR VENT MODE CONTROL SERVO MOTOR (BEHIND CENTER OF DASH) BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLOWER MOTOR (RIGHT SIDE OF DASH) BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE CDS FUSE DEF ED (LEFT FRONT FENDER) ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT) FACE FAN 1 RELAY GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE HOT AT ALL TIMES HTR FUSE LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE MFRS MREC ORG/ WIRE PNK WIRE PNK/BLU WIRE RADIATOR FAN MOTOR RDI FUSE RED WIRE RED/BLU WIRE SG-1 SG-2 SG-3 SG-4 SG-5 SG-6 SG TAM TPI TE TR TSD TSP TPD TPO TPP TELEPHONE COMPUTER (LEFT SIDE OF LUGGAGE COMPT) TELI TPI TW TELI VIO WIRE VIO/WHT WIRE WATER TEMPERATURE SWITCH 1 (RIGHT FRONT OF ENG COMPT) WATER TEMPERATURE SWITCH 2 (REAR OF ENGINE) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE YEL/BLK WIRE YEL/GRN WIRE
