Lexus ES XV30 (2001-2003) sysb si Wiring diagram
This page shows the only wiring diagram for the component.sysb si, which is found in the car Lexus ES XV30 (2001-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sysb si (1 of 1)
15 17 16 12 10 24 22 MMRY
9 10 GND +B
A/T INDICATOR LIGHT SWITCH (ON TRANSAXLE)
BA (UNDER FRONT PASSENGER'S SEAT)
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/ORG WIRE
COM
DEFOGGER SYSTEM
DOWN
DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH)
DRIVING POSITION MEMORY SWITCH
ECU-ACC FUSE
ECU-B FUSE
ECU-IG FUSE
GAUGE 2 FUSE
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START
HSRL
HSRR
J/C 1 (LEFT SIDE OF DASH)
J/C 10 (BEHIND RIGHT SIDE OF DASH)
J/C 3 (LEFT SIDE OF DASH)
J/C 4 (LEFT DASH BRACE)
J/C 6 JUNCTION CONNECTOR (UPPER RIGHT SIDE OF DASH)
J/C 7
J/C 8
J/C 8 JUNCTION CONNECTOR (UPPER RIGHT SIDE OF DASH) OF DASH)
LEFT REMOTE CONTROL MIRROR
LH SELECT SWITCH LH RH RH
LT GRN/RED WIRE
MEMORY MIRROR ECU (BEHIND LOWER CENTER OF DASH)
MEMORY SEAT ECU (BELOW LEFT FRONT SEAT)
PASSENGER SIDE J/B (BEHIND RIGHT SIDE OF DASH)
PNK WIRE
PWR SEAT FUSE
RED/BLU WIRE
RED/WHT WIRE
REMOTE CONTROL MIRROR SWITCH
RIGHT LEFT UP OPERATION SWITCH
RIGHT REMOTE CONTROL MIRROR
SET-
SWE SWB
SWRH SWLH SWVR SWVL VC VSR HSRL M+L MHL MVL
SYSB SI
VIO WIRE
VSRL
VSRR
VSRR HSRR M+R MHR MVR SI
W/ VSC W/O VSC
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Memory mirrors circuit -> SYSB SI
