Lexus ES XV30 (2001-2003) stp wt bz ind Wiring diagram
This page shows the only wiring diagram for the component.stp wt bz ind, which is found in the car Lexus ES XV30 (2001-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram stp wt bz ind (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 WA
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 IG ESS
ABS
BLK WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLU WIRE
BLU/ORG WIRE
BRAKE/
BRN/WHT WIRE
COMBI- NATION METER
COMPUTER DATA LINES SYSTEM
D/G
DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH)
ECU-IG FUSE
ELECTRONIC SUSPENSION SYSTEM
ENG
ENG- TC TRC- PKB RL+ RL- +BO
FRO VSCW RR- RR+
FUSE
GAUGE 1 FUSE
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/RED WIRE
GYAW
HARD NEO
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
HOT IN ON OR START ENGINE ROOM J/B (ON LEFT SIDE OF ENG COMPT)
IA (LEFT DASH REINFORCEMENT)
IB (LEFT DASH BRACE)
LBLO ENG+ TS TRC+
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
MICRO COMPUTER
NCA WIRE
NEO
PARK/ NEUTRAL POSITION SWITCH (ON TRAN- SMISSION)
PASSENGER SIDE J/B (BEHIND RIGHT SIDE OF DASH)
PNK BAT TRIG SS- WIRE
PNK WIRE
PNK/BLK WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
SKID CONTROL ECU (BEHIND RIGHT SIDE OF DASH)
SLIP
STEERING SENSOR (ON STEERING COLUMN)
STOP FUSE
STOPLIGHT SWITCH (BEHIND LEFT SIDE OF DASH)
STP WT BZ IND
TRAC OFF
TRAC OFF SWITCH
TRC+
TRIG CSW
VIO WIRE
VSC
VSC WARNING BUZZER (BEHIND CENTER OF DASH)
VYS
WHT WIRE
WHT/BLK WIRE
YAW -
YEL WIRE
YEL/RED WIRE
YSS
Go to component -> Anti-lock brake circuits, with vsc (2 of 2) -> STP WT BZ IND
