Lexus ES XV30 (2001-2003) starter combination meter Wiring diagram
This page shows the only wiring diagram for the component.starter combination meter, which is found in the car Lexus ES XV30 (2001-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram starter combination meter (1 of 1)
ABS 2 FUSE
ABS 3 FUSE
ABS 4 FUSE
ABS MTR RELAY ABS SOL RELAY
ABS, BA, TRAC, VSC ACTUATOR
AMP FUSE
AST +BM
BLK/GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/RED WIRE
BODY ECU
C/OPN RELAY
CDS FUSE
DOOR 2 FUSE STOP FUSE
DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH)
ENGINE CONTROL FUEL LID OPENNER FOG LIGHT
ENGINE CONTROL MODULE, PARK NEUTRAL POSITION SWITCH
ENGINE CONTROL, STARTING, IGNITION
ENGINE ROOM J/B (ON LEFT SIDE OF ENG COMPT)
ENGINE ROOM R/B (ON LEFT SIDE OF ENG COMPT)
FAN 1 RELAY
FOG FUSE
FROM DRIVER SIDE J/B (DIAGRAM 1 OF 3)
FROM ENGINE ROOM J/B (DIAGRAM 3 OF 3)
FROM ENGINE ROOM RELAY BLOCK (DIAGRAM 1 OF 3)
FUEL OPEN FUSE
FUSE
GRN WIRE
GRN/YEL WIRE
HTR FUSE
HTR RELAY
IGN FUSE
IGNITION SWITCH
LEXUS NAVIGATION SYSTEM, RADIO, PLAYER
LOCK
OBD FUSE FOG RELAY
POWER SEAT, REMOTE CONTROL MIRROR
PWR 1 FUSE
PWR 2 FUSE PWR 3 FUSE
PWR 4 FUSE
PWR SEAT FUSE
RADIATOR FAN, CONDENSER FAN
RDI FUSE
RED WIRE
SKID CONTROL ECU AST
ST FUSE
ST RELAY
STARTER COMBINATION METER
TO DRIVER SIDE J/B (DIAGRAM 1 OF 3)
W/ VSC
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
Go to component -> Power distribution circuit (2 of 3) -> STARTER COMBINATION METER
