Lexus ES XV30 (2001-2003) pnk csl- Wiring diagram
This page shows the only wiring diagram for the component.pnk csl-, which is found in the car Lexus ES XV30 (2001-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk csl- (1 of 1)
+SR P+ P- SIL D- D+ +SL
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 LSP- LSP+
1 2 SFR+ SFR-
AIR BAG SENSOR ASSEMBLY (BEHIND LOWER CENTER OF DASH, ON TRANSMISSION TUNNEL)
AIR BAG SQUIB (STEERING WHEEL PAD)
BB (UNDER FRONT PASSENGER'S SEAT)
BLK WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/YEL WIRE
BODY ECU
BRN WIRE
BRN/WHT WIRE
CSL-
CSR-
DRIVER SIDE J/B (AT LEFT KICK PANEL)
ECU-IG FUSE GSW
ESCL CSL+ VUCL
ESL LBE+
FUSE
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/RED WIRE
HOT IN ON OR START
ICL- ICL+
ID (RIGHT DASH BRACE)
LEFT CURTAIN SHIELD AIR BAG SQUIB
LEFT PRETENSIONER
LEFT SIDE AIR BAG SQUIB
LT GRN/BLK WIRE
LT PNK WIRE
OCCUPANT DETECTION SENSOR
ORG/ WIRE
PASSENGER SIDE J/B (AT RIGHT KICK PANEL)
PBEW LA GSW
PL- PL+
PL- PL+ ICL+ ICL- SFL- SFL+ ESCL VUCL CSL+ VUPL
PNK CSL- WIRE
PNK VUPR CSR+ VUCR ESCR WIRE
PNK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
PNK/GRN WIRE
RBE+ ESR
RED WIRE
RIGHT BUCKLE SWITCH (ON RIGHT FRONT SEAT BELT BUCKLE)
RIGHT CURTAIN SHIELD AIR BAG SENSOR (ABOVE RIGHT REAR FENDERWELL)
RIGHT CURTAIN SHIELD AIR BAG SQUIB
RIGHT PRETENSIONER
RIGHT SIDE AIR BAG SQUIB
SFL- SFL+
SFR+ SFR- ICR- ICR+ PR+ PR-
SL-
TC -SR
VIO WIRE
VUCR ESCR CSR- CSR+
VUPR ESR
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/PNK WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Supplemental restraint circuit (1 of 2) -> PNK CSL- WIRE
