Lexus ES XV30 (2001-2003) headlight beam level indicator Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 IG AIRBAG SENSOR ASSEMBLY (UNDER FRONT OF CENTER FLOOR CONSOLE) BB (UNDER FRONT PASSENGER'S SEAT) BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/RED WIRE BLU WIRE BLU/WHT WIRE BLU/YEL WIRE COMBINATION METER DATA LINK CONNECTOR 3 (AT LOWER LEFT SIDE OF DASH) DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH) ENGINE ROOM J/B (ON LEFT SIDE OF ENGINE COMPARTMENT) FUSE GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/BLK WIRE GRY/RED WIRE HDLP WNG GND HEAD RELAY HEADLIGHT BEAM LEVEL CONTROL ECU (BEHIND LOWER CENTER OF DASH) HEADLIGHT BEAM LEVEL INDICATOR HEIGHT CONTROL SENSOR (BENEATH CENTER REAR OF VEHICLE) HOT AT ALL TIMES HOT IN ON OR START JUNCTION CONNECTOR J/C 1 (BEHIND UPPER LEFT SIDE OF DASH) JUNCTION CONNECTOR J/C 10 (BEHIND LOWER RIGHT SIDE OF DASH) JUNCTION CONNECTOR J/C 14 (NEAR RIGHT FRONT KICK PANEL) JUNCTION CONNECTOR J/C 2 (BEHIND UPPER CENTER OF DASH) JUNCTION CONNECTOR J/C 4 (BEHIND LEFT CENTER OF DASH) JUNCTION CONNECTOR J/C 5 (BEHIND UPPER LEFT SIDE OF DASH) LEFT HEADLIGHT BEAM LEVEL CONTROL ACTUATOR (BEHIND LEFT HEADLIGHT) LT GRN WIRE LT GRN/RED WIRE MAIN FUSE OCCUPANT DETECTION SENSOR ORG/ WIRE PNK/BLK WIRE PRST RBE+ RED/BLK WIRE RED/BLU WIRE RIGHT BUCKLE SWITCH RIGHT HEADLIGHT BEAM LEVEL CONTROL ACTUATOR (BEHIND RIGHT HEADLIGHT) SBR SGR SHG SHB SHRR SHR SKID CONTROL ECU (BEHIND RIGHT SIDE OF DASH) SKID CONTROL ECU WITH ACTUATOR (AT RIGHT SIDE OF ENGINE COMPARTMENT) SPDR VIO WIRE W/ VSC W/O VSC WHT WIRE WHT/BLK WIRE WHT/BLU WIRE YEL WIRE
