Lexus ES XV30 (2001-2003) (except hid type) wiring diagram
This page shows the only wiring diagram for the component.(except hid type), which is found in the car Lexus ES XV30 (2001-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
(except hid type) wiring diagram (1 of 1)
BLK/YEL WIRE
DRL FUSE
DRL NO. 2 RELAY
DRL NO. 3 RELAY
DRL NO. 4 RELAY
EB (RIGHT FRONT FENDER)
EC (LEFT FRONT FENDER)
HEAD LH UPR FUSE
HEAD RH LWR FUSE HEAD LH LWR FUSE
HEAD RH UPR FUSE
HID TYPE
LEFT HEADLIGHT (HIGH)
LEFT HEADLIGHT (LOW)
LEFT HEADLIGHT CONTROL ECU
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT HEADLIGHT (HIGH)
RIGHT HEADLIGHT (LOW)
RIGHT HEADLIGHT CONTROL ECU
WHT/BLK WIRE
WHT/RED WIRE
Go to component -> Headlamps circuit, with drl (2 of 2) -> (EXCEPT HID TYPE)
