Trunk, tailgate, fuel door circuits for Lexus ES XV20 (1996-2001)
Trunk, tailgate, fuel door circuits
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
DOOR FUSE
FUEL LID OPENER MOTOR (ON LEFT SIDE OF LUGGAGE COMPARTMENT)
FUEL LID, LUGGAGE COMPARTMENT DOOR OPENER SWITCH
HOT AT ALL TIMES
INSTRUMENT PANEL JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
J/C 16 (BEHIND TOP CENTER OF DASH)
J/C 34, J/C 35 (RIGHT KICK PANEL)
LUGGAGE COMPARTMENT DOOR OPENER MOTOR (ON CENTER REAR OF DECK LID)
RED WIRE
RED/WHT WIRE
THEFT DETERRENT ECU (UNDER CENTER OF DASH, FORWARD OF CENTER CONSOLE)
TSW
WHT/BLK WIRE
