Cooling fan circuit for Lexus ES XV20 (1996-2001)
Cooling fan circuit
A/C CONDENSER FAN MOTOR
A/C CONTROL ASSEMBLY (CENTER OF DASH)
A/C DIODE (NEAR REAR OF ENGINE ROOM JUNCTION BLOCK)
A/C SINGLE PRESSURE SWITCH (ON REFRIGERANT LINE, NEAR RECEIVER-DRIER)
ALT FUSE
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
CDS FUSE
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
ENGINE MAIN RELAY
ENGINE ROOM RELAY BLOCK (IN ENGINE ROOM JUNCTION BLOCK) FAN 3 RELAY
FAN 1 RELAY
FAN 2 RELAY
FUSIBLE LINK BLOCK (IN ENGINE ROOM JUNCTION BLOCK)
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
INSTRUMENT PANEL JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) ECU-IG FUSE
MGCR
RADIATOR FAN MOTOR
RDI FUSE
RED WIRE
WATER TEMPERATURE SWITCH 1 (IN LEFT FRONT OF ENGINE COMPT)
WATER TEMPERATURE SWITCH 2 (ON TOP LEFT REAR OF ENGINE)
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
