Lexus ES XV20 (1996-2001) rear vertical Wiring diagrams
This page contains all the electrical diagrams for the component. rear vertical, in which he is found in the car Lexus ES XV20 (1996-2001). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rear vertical (1 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 SSRS SSRV SSRR PVCC
1 2 3 4 5 6 7 8 9 10 RCL- RCL+ SLD- SLD+ RRV- RRV+ GND +B FRV- FRV+
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
DOWN
DRIVER'S POWER SEAT CONTROL SWITCH
DRIVER'S SEAT FRONT VERTICAL POSITION SENSOR
DRIVER'S SEAT FRONT VERTICAL POWER SEAT MOTOR
DRIVER'S SEAT LUMBAR SUPPORT MOTOR
DRIVER'S SEAT REAR VERTICAL POSITION SENSOR
DRIVER'S SEAT REAR VERTICAL POWER SEAT MOTOR
DRIVER'S SEAT RECLINING POSITION SENSOR
DRIVER'S SEAT RECLINING POWER SEAT MOTOR
DRIVER'S SEAT SLIDE POSITION SENSOR
DRIVER'S SEAT SLIDE POWER SEAT MOTOR
ECU-B FUSE
ECU-IG FUSE
ENGINE ROOM JUNCTION BLOCK (ON LEFT SIDE OF ENGINE COMPT)
FRONT
FRONT VERTICAL
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
J/C 30 (RIGHT SIDE OF DASH)
J/C 37 (LOWER LEFT "B" PILLAR)
J/C 5 (LEFT SIDE OF DASH)
LEFT FRONT DOOR COURTESY SWITCH
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
LUMBAR SUPPORT SWITCH
MEMORY SEAT SWITCH
MMRY DCTY SYSB SSFV SGND SLDF SLDR RUP RDWN FUP FDWN RCLF RCLR IG
PARK/ NEUTRAL POSITION SWITCH
PNK WIRE
REAR
REAR VERTICAL
RECLINING
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
SEAT POSITION CONTROL ECU (UNDER DRIVER'S SEAT)
SET-
SLIDE
STOP
STOP FUSE
STOPLIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
VIO WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Memory system circuits -> REAR VERTICAL
Wiring diagram rear vertical (2 of 2)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
DOWN
DRIVER'S POWER SEAT LUMBAR SUPPORT CONTROL SWITCH
DRIVER'S SEAT
DRIVER'S SEAT LUMBAR SUPPORT CONTROL MOTOR (UNDER SEAT)
FRONT
FRONT VERTICAL
FRONT VERTICAL CONTROL MOTOR (UNDER SEAT)
HOT AT ALL TIMES
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
J/C 37 (LOWER LEFT "B" PILLAR)
LT GRN WIRE
POWER FUSE
REAR
REAR VERTICAL
REAR VERTICAL CONTROL MOTOR (UNDER SEAT)
RECLINING
RECLINING CONTROL MOTOR (UNDER SEAT)
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
SLIDE
SLIDE CONTROL MOTOR (UNDER SEAT)
WHT WIRE
WHT/BLK WIRE
Go to component -> Power seats circuit -> REAR VERTICAL
