Lexus ES XV20 (1996-2001) open/ down close/ up Wiring diagram
This page shows the only wiring diagram for the component.open/ down close/ up, which is found in the car Lexus ES XV20 (1996-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram open/ down close/ up (1 of 1)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
CLOSE/ UP
DOME FUSE
DOOR FUSE
ENGINE ROOM JUNCTION BLOCK (ON LEFT SIDE OF ENGINE COMPARTMENT)
GAUGE FUSE
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGN
INSTRUMENT PANEL JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
INTEGRATION RELAY
J/C 15 (BEHIND CENTER OF DASH)
J/C 28 (BEHIND RIGHT SIDE OF DASH)
J/C 33 (BEHIND RIGHT END OF DASH)
J/C 34, J/C 35 (RIGHT KICK PANEL)
J/C 7 (BEHIND LEFT END OF DASH)
LEFT FRONT DOOR KEY LOCK/ UNLOCK SWITCH
MOON ROOF CONTROL SWITCH
MOON ROOF LIMIT SWITCH
MOON- ROOF MOTOR
OPEN/ DOWN
OPEN/ DOWN CLOSE/ UP
POWER FUSE
PWR
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT DOOR COURTESY SWITCH
RIGHT FRONT DOOR KEY LOCK/ UNLOCK SWITCH
TO POWER DISTRIBUTION
WHT WIRE
WHT/BLK WIRE
WOPN WCLS
Go to component -> Power top/sunroof circuits -> OPEN/ DOWN CLOSE/ UP
