Lexus ES XV20 (1996-2001) driver's lumbar seat control switch Wiring diagram
This page shows the only wiring diagram for the component.driver's lumbar seat control switch, which is found in the car Lexus ES XV20 (1996-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's lumbar seat control switch (1 of 1)
BUCKLE SWITCH
CELLULAR PHONE
CLOCK
COMBINATION METER
DRIVER'S LUMBAR SEAT CONTROL SWITCH
DRIVER'S POWER SEAT CONTROL SWITCH
DRIVER'S SEAT HEATER FUEL LID OPENER MOTOR
DRIVER'S SEAT HEATER SWITCH
FUEL LID, LUGGAGE COMPARTMENT DOOR OPENER SWITCH
FUEL PUMP
GLOVE BOX LIGHT SWITCH
HIGH MOUNTED STOP LIGHT
J/C 16 (BEHIND CENTER OF DASH)
J/C 37 (LOWER LEFT "B" PILLAR)
LEFT LICENSE PLATE LIGHT
LEFT REAR ABSORBER CONTROL ACTUATOR
LEFT REAR COMBINATION LIGHT
LEFT REAR DOOR LOCK MOTOR, DOOR UNLOCK DETECTION SWITCH
LEFT REAR SIDE MARKER LIGHT LEFT REAR COMBINATION LIGHT
LEFT REAR TURN SIGNAL LIGHT
LIGHT FAILURE SENSOR
LUGGAGE COMPARTMENT DOOR KEY UNLOCK SWITCH
O/D MAIN SWITCH
PASSENGER'S SEAT HEATER SWITCH
REMOTE CONTROL MIRROR SWITCH
RHEOSTAT
RIGHT LICENSE PLATE LIGHT
RIGHT REAR COMBINATION LIGHT
RIGHT REAR SIDE MARKER LIGHT
RIGHT REAR TURN SIGNAL LIGHT
SEAT POSITION CONTROL ECU
SHIFT LOCK CONTROL ECU
TELEPHONE TRANSCEIVER/ SPEAKER RELAY
THEFT DETERRENT ECU
W/ DRIVING POSITION MEMORY
W/O DRIVING POSITION MEMORY
WHT/BLK WIRE
WIRELESS DOOR LOCK ECU
Go to component -> Ground distribution circuit (3 of 4) -> DRIVER'S LUMBAR SEAT CONTROL SWITCH
