Lexus ES XV20 (1996-2001) automatic light control sensor (top left or right side of dash) wiring diagram
This page shows the only wiring diagram for the component.automatic light control sensor (top left or right side of dash), which is found in the car Lexus ES XV20 (1996-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
automatic light control sensor (top left or right side of dash) wiring diagram (1 of 1)
AUTO OFF TAIL
AUTOMATIC LIGHT CONTROL SENSOR (TOP LEFT OR RIGHT SIDE OF DASH)
BLU/YEL WIRE
CLTS CLTB CLTE
COMBINATION SWITCH
EXTERIOR LIGHTS SYSTEM (TAILLIGHT RELAY)
FLASH DIMMER SWITCH
FLASH LOW
FOG FUSE
FOGLIGHT SWITCH
FRONT FOGLIGHT RELAY (BEHIND LEFT SIDE OF DASH)
GAUGE FUSE
GRN WIRE
GRN/RED WIRE
GRY/RED WIRE
HEAD
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
INTEGRATION RELAY
J/C 15 (BEHIND CENTER OF DASH)
J/C 18, J/C 19 (RIGHT SIDE OF DASH)
J/C 31, J/C 32 (BEHIND RIGHT SIDE OF DASH)
J/C 8 (LEFT SIDE OF DASH)
LEFT FRONT DOOR COURTESY SWITCH
LEFT FRONT FOGLIGHT
LIGHT CONTROL SWITCH
LOW HIGH
PNK/BLU WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT FOGLIGHT
VIO/YEL WIRE
WHT/BLK WIRE
Go to component -> Headlight circuit, without drl (1 of 2) -> AUTOMATIC LIGHT CONTROL SENSOR (TOP LEFT OR RIGHT SIDE OF DASH)
