Trunk & fuel door release circuit for Lexus ES XV10 facelift (1994-1996)

Trunk & fuel door release circuit

Get access

BLK/RED WIRE BLU WIRE BLU/RED WIRE BLU/YEL WIRE CIG FUSE ECU-IG FUSE FUEL LID OPENER SOLENOID (LEFT SIDE OF TRUNK) FUEL LID OPENER SWITCH HOT AT ALL TIMES POWER FUSE HOT IN ACCY OR RUN HOT IN RUN J/B 1 (LEFT SIDE OF I/P) J/C 2 (RIGHT SIDE OF I/P) J/C 3 (RIGHT SIDE OF I/P) J/C 5 (LEFT SIDE OF TRUNK) LUGGAGE COMPARTMENT DOOR OPENER MAIN SWITCH LUGGAGE COMPARTMENT DOOR OPENER MOTOR (CENTER REAR OF TRUNK) LUGGAGE COMPARTMENT DOOR OPENER SWITCH RED WIRE RED/WHT WIRE THEFT DETERRENT, DOOR LOCK ECU (RIGHT SIDE OF I/P) TRK TO WHT/BLK WIRE WHT/BLU WIRE
