Transmission circuit for Lexus ES XV10 facelift (1994-1996)

+B BK 1 4 7 9 20 22 CONN B VC 2 3 6 7 10 11 12 14 15 22 23 24 CONN D 3 11 17 27 28 32 33 34 CONN A SLN- 5 16 CONN C A/T INDICATOR SWITCH (LEFT SIDE OF ENGINE COMPARTMENT) BLK ORG/ WIRE BLK WIRE BLK/ORG WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE CRUISE CONTROL ECU (BEHIND RIGHT SIDE OF I/P) DATA LINK CONNECTOR 1 (CHECK CONNECTOR) (RIGHT REAR ENG COMPT) ECT ECT INDIC O/D INDIC SPEEDO L INDIC 2 INDIC D INDIC N INDIC R INDIC P INDIC EFI FUSE EFI MAIN RELAY ELECTRONC CONTROLLED TRANSMISSION SOLENOID (LEFT SIDE OF ENGINE COMPARTMENT) ELECTRONIC CONTROLLED TRANSMISSION PATTERN SELECT SWITCH ENGINE COOLANT TEMPERATURE SENSOR (RIGHT SIDE OF ENGINE COMPARTMENT) ENGINE, ELECTRONIC CONTROLLED TRANSMISSION ECU (BEHIND RIGHT SIDE OF I/P) GAUGE FUSE GRN RED/ WIRE GRN WIRE GRN/ WHT WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT IN ON OR START IDL IGN FUSE INSTRUMENT CLUSTER SYSTEM J/B 1 (LEFT SIDE OF I/P) J/B 2 (LEFT SIDE OF ENGINE COMPARTMENT) J/B 3 (BEHIND COMBINATION METER) J/C 1 (BEHIND LEFT SIDE OF I/P) J/C 2 (BEHIND RIGHT SIDE OF I/P) J/C 6 (LEFT SIDE OF ENGINE COMPT.) J/C 7 (BEHIND RIGHT SIDE OF ENGINE COMPARTMENT) LEFT FRONT FENDER) NO.1 NO.2 NO.3 (LOCK-UP) NORMAL 5 6 4 3 O/D DIRECT CLUTCH SPEED SENSOR (LEFT ENG COMPT) O/D MAIN SWITCH ORG/ WIRE PNK/BLU WIRE PWR RED WIRE RED/BLK WIRE RED/BLU WIRE STARTING/ CHARGING SYSTEM STOP FUSE STOP LIGHT SWITCH (BRAKE PEDAL BRACKET) THROTTLE POSITION SENSOR (ON THROTTLE BODY ASSEMBLY) VIO WIRE VIO/RED WIRE VIO/YEL VIO/YEL WIRE VIO/YEL WIRE WHT WIRE WHT/ BLK WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE
