Car Wiring Diagrams for Power seat circuits for Lexus ES XV10 facelift (1994-1996)

BLK WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE DOWN UP FRONT FRONT DOWN FRONT VERTICAL FRONT VERTICAL MOTOR (UNDER RIGHT SEAT) GRN WIRE HOT AT ALL TIMES HOT IN ON OR START SEAT/HTR FUSE J/B 1 (LEFT SIDE OF I/P) J/C 2 (BEHIND CENTER OF I/P) J/C 5 (LEFT REAR OF TRUNK) LEFT CUSHION HEATER LEFT POWER SEAT CONTROL SWITCH LEFT SEAT HEATER (BACKREST) LEFT SEAT HEATER SWITCH POWER FUSE REAR REAR FRONT REAR VERTICAL REAR VERTICAL MOTOR (UNDER LEFT SEAT) REAR VERTICAL MOTOR (UNDER RIGHT SEAT) RECLINE MOTOR (UNDER LEFT SEAT) FRONT VERTICAL MOTOR (UNDER LEFT SEAT) RECLINE MOTOR (UNDER RIGHT SEAT) RECLINING RECLINING FRONT VERTICAL RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RIGHT CUSHION HEATER RIGHT POWER SEAT CONTROL SWITCH RIGHT SEAT HEATER (BACKREST) RIGHT SEAT HEATER SWITCH SLIDE SLIDE MOTOR (UNDER LEFT SEAT) SLIDE MOTOR (UNDER RIGHT SEAT) UP DOWN UP REAR WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE
