Power antenna circuit for Lexus ES XV10 facelift (1994-1996)

Power antenna circuit

Get access

1 7 AMP+ 1995 ONLY AUTO ANTENNA MOTOR, RELAY (RIGHT REAR OF TRUNK) BLK WIRE BLK/RED WIRE BLU/RED WIRE BLU/YEL WIRE CIG/RADIO FUSE ECU-IG FUSE HOT AT ALL TIMES J/B 2 (LEFT SIDE OF ENG COMPT) DOME FUSE HOT IN ON OR ACCY HOT IN ON OR START J/B 1 (LEFT SIDE OF I/P) J/C 2 (TOP CENTER OF I/P) J/C 3 (RIGHT SIDE OF I/P) LT GRN/RED WIRE PNK/BLU WIRE RADIO, PLAYER (CENTER OF I/P) RED WIRE RED/GRN WIRE RED/WHT WIRE STEREO COMPONENT AMPLIFIER (BELOW CONSOLE) WHT/BLK WIRE YEL WIRE
