Courtesy lamps circuit for Lexus ES XV10 facelift (1994-1996)

2 4 (W/O MOON) (W/ MOON) BLK WIRE CIG/RADIO FUSE DIODE (CENTER BACK PANEL) DOOR DOOR IND DSWD DSWP GAUGE FUSE GRN/RED (OR RED/WHT) WIRE GRN/RED WIRE HOT AT ALL TIMES J/B 2 (LEFT SIDE OF ENG COMPT) DOME FUSE HOT IN ON OR ACCY HOT IN ON OR START IGNITION KEY CYLINDER LIGHT INSTRUMENT CLUSTER INTEGRATION RELAY INTERIOR LIGHT) J/B 1 (LEFT SIDE OF I/P) J/B 3 (BEHIND INSTRUMENT CLUSTER) J/C 3 (CENTER OF I/P) LEFT FRONT DOOR COURTESY LIGHT LEFT FRONT DOOR COURTESY SWITCH (NEAR LEFT FRONT DOOR LATCH) LEFT REAR DOOR COURTESY SWITCH (NEAR LEFT REAR DOOR LATCH) LEFT VANITY LIGHT LUGGAGE COMPARTMENT LIGHT LUGGAGE COMPARTMENT LIGHT SWITCH (CENTER BACK PANEL) OFF OFF OFF PERSONAL LIGHT RED WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT DOOR COURTESY LIGHT RIGHT FRONT DOOR COURTESY SWITCH (NEAR RIGHT FRONT DOOR LATCH) RIGHT REAR DOOR COURTESY SWITCH (NEAR RIGHT REAR DOOR LATCH) RIGHT VANITY LIGHT THEFT DETERRENT, DOOR LOCK ECU (RIGHT SIDE OF I/P) W/ MOON- ROOF W/O MOON- ROOF W/O MOON- ROOF W/ MOON- ROOF WHT WIRE WHT/ BLK WIRE WHT/BLK WIRE WIRELESS DOOR LOCK ECU (RIGHT REAR OF TRUNK)
