Wiring diagram engine performance 3.0ls for Lexus ES XV10 facelift (1994-1996)

#60 #50 #40 #30 #20 #10 A/T ONLY BLK WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE CAMSHAFT POSITION SENSOR (LOWER LEFT FRONT OF ENGINE) CIRCUIT OPENING RELAY CRANKSHAFT POSITION SENSOR (LOWER RIGHT FRONT OF ENGINE) CRUISE CONTROL SYSTEM EFI MAIN RELAY ELECTRONIC CONTROLLED TRANSMISSION SOLENOID FC OXL THW THA FPU FUEL PUMP (ON TOP OF FUEL TANK) GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT AT ALL TIMES EFI FUSE HOT IN IDL IGF GND IGF STA NSW IGN FUSE IGNITER (LEFT SIDE OF ENGINE COMPARTMENT) IGNITION COIL NO.1 IGNITION COIL NO.3 IGNITION COIL NO.4 IGNITION COIL NO.2 IGNITION COIL NO.6 IGNITION COIL NO.5 IGNITION SWITCH INJECTOR NO 2 INJECTOR NO 5 INJECTOR NO 6 INJECTOR NO. 3 INJECTOR NO. 4 J/B 1 (LEFT SIDE OF I/P) J/B 3 (BEHIND COMBI- NATION METER) CUT- OFF J/B 3 (BEHIND COMBINATION METER) J/B NO.2 (LEFT SIDE OF ENGINE COMPARTMENT) J/C 7 (BEHIND RIGHT SIDE OF I/P) J/C 8 (BEHIND RIGHT SIDE OF I/P) KNOCK SENSOR 1 (TOP FRONT OF ENGINE) KNOCK SENSOR 2 (TOP FRONT OF ENGINE) LEFT FRONT FENDER) LOCK ON LOCK-UP #2 LT GRN WIRE NE+ NE- VTA VG NOISE FILTER (LEFT SIDE OF ENGINE COMPT.) O/D DIRECT CLUTCH SPEED SENSOR ORG/ WIRE OXR KNKL KNKR PNK WIRE PNK/BLU WIRE R/B NO. 1 (LEFT KICK PANEL) STARTER FUSE R/B NO. 6 (BEHIND GLOVE BOX) RED WIRE RED/BLK WIRE RED/BLU WIRE RSC RSO SLN- STARTING/ CHARGING SYSTEM (STARTING CIRCUIT) TACH (LEFT I/P BRACE) VIO WIRE W/ELEC. TRANSMISSION INJECTOR NO. 1 W/O ELEC. TRANS. WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE

A/C IDLE-UP VALVE (LEFT REAR SIDE OF ENGINE) A/T ONLY BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE COMBINATION METER COOLING FANS SYSTEM (COOLING FAN ECU) CRUISE CONTROL CRUISE CONTROL SYSTEM ECT PWR. EGR GAS TEMPERATURE SENSOR (LEFT REAR OF ENGINE) EGR VALVE (TOP CENTER OF ENGINE) ELECTRONIC CONTROLLED ENGINE COOLANT TEMPERATURE SENSOR (RIGHT SIDE OF ENGINE) EVAP VALVE (ON TOP OF ENGINE) (CALIF. MODELS) FUEL PRESSURE UP VALVE (TOP LEFT SIDE OF ENGINE) GAUGE FUSE GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE GRN/YEL WIRE HOT IN ON OR START IDLE AIR CONTROL VALVE (LEFT REAR SIDE OF ENGINE) INTAKE AIR CONTROL VALVE (RIGHT SIDE OF ENGINE) J/B 1 (LEFT SIDE OF I/P) J/B 3 (BEHIND COMBI- NATION METER) J/C 1 (BEHIND LEFT SIDE OF I/P) J/C 2 (BEHIND CENTER OF I/P) J/C 8 (BEHIND RIGHT SIDE OF I/P) LT GRN WIRE MALF IND LAMP O/D OFF IND NORM. PWR. TRANSMISSION PATTERN SELECT SWITCH (ON CONSOLE) (A/T ONLY) O/D MAIN SWITCH (IN CONSOLE) ORG/ WIRE PNK WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/YEL WIRE SPEEDOMETER TACHO- METER THROTTLE POSITION SENSOR (LEFT REAR OF ENGINE) VEHICLE SPEED SENSOR (ON TRANSMISSION) VIO WIRE VIO/YEL WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE

+B STP HTS OXS 1 PNK/ WIRE 2 3 4 5 VG THA A/C ELS ACIS VG- ACT ACV AIR CONDITIONING SYSTEM BAT SG CG SDL DATA LINK CONNECTOR 3 (BEHIND LEFT SIDE OF I/P) BATT BATT BLK WIRE BLK/ WHT WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BRN WIRE CF 2 CRUISE CONTROL SYSTEM GRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE HEATED OXYGEN SENSOR (BANK 1 SENSOR 1) (CENTER REAR OF ENGINE) HEATED OXYGEN SENSOR (BANK 1 SENSOR 2) (UNDER CENTER OF VEHICLE) HEATED OXYGEN SENSOR (BANK 2 SENSOR 1) (TOP RIGHT SIDE OF ENGINE) HOT AT ALL TIMES HOT AT ALL TIMES J/B 2 (LEFT SIDE OF ENGINE COMPT.) OBD FUSE HTL HTR EGR HTS IDLE-UP DIODE (BEHIND RIGHT SIDE OF I/P) J/B 1 (LEFT SIDE OF I/P) J/B 1 (LEFT SIDE OF I/P) STOP FUSE J/B 3 (BEHIND COMBINATION METER) J/C 1 (BEHIND LEFT SIDE OF I/P) J/C 7 (BEHIND RIGHT SIDE OF I/P) LT GRN/RED WIRE MASS AIR FLOW METER (LEFT REAR CORNER ORG/ WIRE OXS PNK WIRE PNK/BLK WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/YEL WIRE SDL - STOP LIGHT SWITCH (BEHIND LEFT SIDE OF I/P) THG VG- +B VIO WIRE VIO/YEL WIRE WHT WIRE WHT/BLK OR WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE YEL/BLK WIRE YEL/BLU WIRE
