Lexus ES XV10 facelift (1994-1996) theft deterrent indicator light Wiring diagram
This page shows the only wiring diagram for the component.theft deterrent indicator light, which is found in the car Lexus ES XV10 facelift (1994-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram theft deterrent indicator light (1 of 1)
A/C POWER TRANSISTOR
AIR VENT MODE CONTROL SERVO MOTOR
BLK WIRE
BLOWER RESISTOR
BRAKE FLUID LEVEL SWITCH TURN SIGNAL FLASHER
CANADA ONLY
CENTER AIRBAG SENSOR ASSEMBLY
CIGARETTE LIGHTER
CIRCUIT OPENNING RELAY
CRUISE CONTROL ECU
CRUISE CONTROL SWITCH (INSTRUMENT CLUSTER)
DATA LINK CONNECTOR 3
DAYTIME RUNNING LIGHT RELAY
DIMMER SWITCH (COMB SW)
EXTRA HIGH SPEED RELAY
HEATER MAIN RELAY
HIGH BEAM INDICATOR LIGHT
IGNITION SW
INSTRUMENT CLUSTER
INTEGRATION RELAY
J/B 1 NOISE FILTER
J/B 3
J/C 1
KEY INTERLOCK SOLENOID
LEFT VANITY LIGHT
LIGHT CONTROL SWITCH (COMB SW)
MOON ROOF CONTROL RELAY
MOON ROOF CONTROL SWITCH
MOON ROOF LIMIT SWITCH
MOON- ROOF MOTOR
PERSONAL LIGHT
POWER MAIN RELAY
PPS ECU
R/B 1
R/B 4
R/B 6
REAR WINDOW DEFOGGER SWITCH (A/C CONTROL ASSEMBLY)
RHEOSTAT
RIGHT VANITY LIGHT
THEFT DETERRENT INDICATOR LIGHT
UNLOCK WARNING SWITCH
W/ MOON- ROOF
W/O MOON- ROOF
WHT WIRE
WHT/BLK WIRE
WIPER CONTROL RELAY
WIPER/ WASHER SWITCH (COMB SW)
Go to component -> Ground distribution circuit (3 of 3) -> THEFT DETERRENT INDICATOR LIGHT
