Lexus ES XV10 facelift (1994-1996) tail light relay Wiring diagrams
This page contains all the electrical diagrams for the component. tail light relay, in which he is found in the car Lexus ES XV10 facelift (1994-1996). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram tail light relay (1 of 2)
BLK WIRE
BLU/YEL WIRE
COMBINATION SWITCH
DIMMER SWITCH
DIODE
DOME FUSE
ECU-B FUSE
FOG LIGHT SWITCH
GAUGE FUSE
GRN WIRE
GRN/RED WIRE
HEADLIGHT RELAY
HIGH FLASH LO LO
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE BOX ALT FUSE (LEFT FRONT OF ENG COMPT)
HOT IN ON
INTEGRATION RELAY
J/B 1 (LEFT SIDE OF I/P)
J/B 2 (LEFT SIDE OF ENG COMPT)
J/B 3 (BEHIND INSTRUMENT CLUSTER)
LEFT FRONT DOOR COURTESY SWITCH (NEAR LEFT FRONT DOOR LATCH)
LIGHT CONTROL SWITCH
ON OFF
PARK BRAKE SWITCH (BELOW CENTER CONSOLE)
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
ST MAIN FUSE
TAIL FUSE
TAIL HEAD OFF OFF
TAIL LIGHT RELAY
WHT WIRE
WHT/BLK WIRE
Go to component -> Headlight circuit, with drl (1 of 2) -> TAIL LIGHT RELAY
Wiring diagram tail light relay (2 of 2)
1995 ONLY
BLK/ WHT WIRE
CDS FUSE
COMBINATION SWITCH
DIMMER SWITCH
DIODE
DOME ST MAIN FUSE FUSE
FOG FUSE
FOG LIGHT RELAY
FOG LIGHT SWITCH
GAUGE FUSE
GRN WIRE
GRN/RED WIRE
HEAD FUSE (LH)
HEAD FUSE (RH)
HEAD- LIGHT IND
HEAD- LIGHT RELAY
HIGH BEAM IND
HIGH FLASH LO
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE BOX ALT FUSE (LEFT FRONT OF ENG COMPT)
HOT IN RUN
INSTRUMENT CLUSTER
INTEGRATION RELAY
J/B 1 (LEFT SIDE OF I/P)
J/B 2 (LEFT SIDE OF ENG COMPT)
J/B 2 (LEFT SIDE OF ENGINE COMPT)
J/B 3 (BEHIND CLUSTER)
LEFT FOG LIGHT
LEFT FRONT DOOR COURTESY SWITCH (NEAR LEFT FRONT DOOR LATCH)
LEFT HI BEAM HEAD- LIGHT
LEFT LO BEAM HEADLIGHT
LIGHT CONTROL SWITCH OFF
R/B 5 (LEFT SIDE OF ENG COMPT)
RED WIRE
RED YEL/ WIRE
RED/ BLK WIRE
RED/ WHT WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FOG LIGHT
RIGHT HI BEAM HEAD- LIGHT
RIGHT LO BEAM HEADLIGHT
TAIL FUSE
TAIL HEAD OFF OFF
TAIL LIGHT RELAY
THEFT DETERRENT, DOOR LOCK ECU (RIGHT SIDE OF I/P)
WHT WIRE
WHT/ BLK WIRE
WHT/BLK WIRE
Go to component -> Headlight circuit, without drl -> TAIL LIGHT RELAY
