Lexus ES XV10 facelift (1994-1996) remote control mirror swich Wiring diagram
This page shows the only wiring diagram for the component.remote control mirror swich, which is found in the car Lexus ES XV10 facelift (1994-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram remote control mirror swich (1 of 1)
BLK WIRE
BLU/RED WIRE
BRN WIRE
DEFOGGER SYSTEM
DOWN
GRN WIRE
HOT IN ACCY OR ON CIG/RADIO FUSE
J/B 1 (LEFT SIDE OF I/P)
J/C 2 (CENTER OF I/P)
LEFT
LEFT REMOTE CONTROL MIRROR
LEFT UP
LT GN/
LT GRN WIRE
LT GRN/RED WIRE
LT LT
RED WIRE
RED/BLK WIRE
REMOTE CONTROL MIRROR SWICH
RIGHT
RIGHT DOWN
RIGHT LEFT
RIGHT REMOTE CONTROL MIRROR
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power mirror circuit -> REMOTE CONTROL MIRROR SWICH
