Lexus ES XV10 facelift (1994-1996) reclining front vertical Wiring diagram
This page shows the only wiring diagram for the component.reclining front vertical, which is found in the car Lexus ES XV10 facelift (1994-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram reclining front vertical (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
DOWN UP
FRONT
FRONT DOWN
FRONT VERTICAL
FRONT VERTICAL MOTOR (UNDER RIGHT SEAT)
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START SEAT/HTR FUSE
J/B 1 (LEFT SIDE OF I/P)
J/C 2 (BEHIND CENTER OF I/P)
J/C 5 (LEFT REAR OF TRUNK)
LEFT CUSHION HEATER
LEFT POWER SEAT CONTROL SWITCH
LEFT SEAT HEATER (BACKREST)
LEFT SEAT HEATER SWITCH
POWER FUSE
REAR
REAR FRONT
REAR VERTICAL
REAR VERTICAL MOTOR (UNDER LEFT SEAT)
REAR VERTICAL MOTOR (UNDER RIGHT SEAT)
RECLINE MOTOR (UNDER LEFT SEAT) FRONT VERTICAL MOTOR (UNDER LEFT SEAT)
RECLINE MOTOR (UNDER RIGHT SEAT)
RECLINING
RECLINING FRONT VERTICAL
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT CUSHION HEATER
RIGHT POWER SEAT CONTROL SWITCH
RIGHT SEAT HEATER (BACKREST)
RIGHT SEAT HEATER SWITCH
SLIDE
SLIDE MOTOR (UNDER LEFT SEAT)
SLIDE MOTOR (UNDER RIGHT SEAT)
UP DOWN
UP REAR
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Power seat circuits -> RECLINING FRONT VERTICAL
