Lexus CT I (2010-2014) window lock switch indicator wiring diagram
This page shows the only wiring diagram for the component.window lock switch indicator, which is found in the car Lexus CT I (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
window lock switch indicator wiring diagram (1 of 1)
+ECU
31 29 32 30 ALTB
9 10 3 CANP CANN
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONTROL CIRCUIT
DOOR 1 FUSE
DOOR R/L FUSE
DOOR R/R FUSE
DRIVER SIDE AUTO SWITCH
DRIVER SIDE DOWN SWITCH
DRIVER SIDE UP SWITCH
DRIVER'S DOOR
FRONT PASSENGER SIDE CONTROL SWITCH
FUSE
GRN WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) ECU-B FUSE
HOT AT ALL TIMES INSTRUMENT PANEL J/B D FR DOOR FUSE (BEHIND LEFT END OF DASH)
HOT IN ACC OR ON
HOT IN ON OR START
IG BECU LIN 2 FLCY
INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH)
LED
LEFT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY (LEFT "B" PILLAR)
LEFT REAR SIDE CONTROL SWITCH
MAIN BODY ECU
MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY
P FR DOOR FUSE
PNK WIRE
POWER WINDOW INDICATOR
RED WIRE
RIGHT REAR SIDE CONTROL
SWITCH
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WINDOW LOCK SWITCH
WINDOW LOCK SWITCH INDICATOR
YEL WIRE
Go to component -> Power windows circuit (1 of 2) -> WINDOW LOCK SWITCH INDICATOR
