Lexus CT I (2010-2014) down front wiring diagram
This page shows the only wiring diagram for the component.down front, which is found in the car Lexus CT I (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
down front wiring diagram (1 of 1)
BLK WIRE
BLU WIRE
DOWN
DOWN FRONT
DRIVER'S SEAT LIFT MOTOR (BOTTOM OF DRIVER'S SEAT)
DRIVER'S SEAT RECLINING MOTOR (DRIVER'S SEAT)
DRIVER'S SEAT SLIDE MOTOR (BOTTOM OF DRIVER'S SEAT)
DRIVER'S SEAT TILT MOTOR (BOTTOM OF DRIVER'S SEAT)
FRONT
FRONT VERTICAL
GRN WIRE
GRY WIRE
HOT AT ALL TIMES PWR SEAT FUSE
INSTRUMENT PANEL J/B (BEHIND LEFT END OF DASH)
LEFT "C" PILLAR)
LEFT FRONT POWER SEAT SWITCH
LEFT LUMBAR SUPPORT SWITCH
LIFTER
LT BLU WIRE
LT GRN WIRE
LUMBAR
PNK WIRE
REAR UP
RECLINING
RED WIRE
SLIDE
UP REAR
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Driver power seat circuit -> DOWN FRONT
