Land Rover Range Rover L322 (2009-2012) Climate control seats circuit

BATT 1 BATT 2 BLK WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CENTRAL JUNCTION BOX COMPUTER DATA LINES SYSTEM DRIVER'S SEAT CUSHION HEATER FRONT PASSENGER'S SEAT CUSHION HEATER FUSE 21 FUSE 29 FUSE 33 GRN WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT W/ IGNITION RELAY ENERGIZED IGN LEFT BACKREST HEATER LH BACK BLOW SPD LH BACK SEN RTN LH BACK SEN SIG LH BACK TED - LH CUSH BLOW SPD LH CUSH SEN RTN LH CUSH SEN SIG LH CUSH TED - LH SEAT BLOWER + MS CAN-HI MS CAN-LO ORG/ WIRE ORG/GRN WIRE ORG/YEL WIRE PNK WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE RED/ORG WIRE RED/WHT WIRE RED/YEL WIRE RH BACK BLOW SPD RH BACK SEN RTN RH BACK SEN SIG RH BACK TED - RH CUSH BLOW SPD RH CUSH SEN RTN RH CUSH SEN SIG RH CUSH TED - RH SEAT BLOW + RIGHT BACKREST HEATER SEAT CLIMATE CONTROL MODULE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/WHT WIRE
