Diagnostic socket circuit for Land Rover Range Rover L322 (2009-2012)

ABS MODULE (LEFT REAR OF ENGINE COMPT) AFS CONTROL MODULE (BEHIND GLOVE BOX) ANALOG CLOCK BATTERY MONITORING SYSTEM MODULE BLK WIRE BLU/BRN WIRE BRN WIRE BRN/WHT WIRE CAMERAS MODULE CCP CAN HI CCP CAN LO CENTRAL ELECTRONICS MODULE (CEM) CENTRAL JUNCTION BOX CLOCK- SPRING DIAG K DIAGNOSTIC SOCKET DRIVER DOOR MODULE DRIVER MIRROR WINDOW SWITCH PACK ENGINE CONTROL MODULE (RIGHT SIDE OF ENGINE COMPT) FUSE 66 GENERATOR GRN WIRE GRN/BLK WIRE GRN/WHT WIRE HOT AT ALL TIMES HS CAN HI HS CAN LO HS CAN-H HS CAN-L IMMOBILISER ANTENNA MODULE INSTRUMENT CLUSTER K LINE LEFT REAR DOOR MODULE (IN REAR DOOR) LEFT STEERING WHEEL MODULE LIN 1 LIN 2 LIN 3 LIN 4 LIN 5 LIN A MS CAN-HI MS CAN-LO NCA WIRE RAIN SENSOR REAR CLIMATE SEATS MODULE RED WIRE RED/GRN WIRE ROOF OPENING PANEL CONTROL MODULE SOUNDER BATTERY BACKED PLUS TILT SENSOR STEERING ANGLE SENSOR STEERING COLUMN LOCK MODULE TCM, CONTROL VALVE BODY (UNDER GEAR BOX) TRANSFER BOX CONTROL MODULE (LEFT REAR OF ENGINE COMPT) TRANSIT RELAY VOLUMETRIC SENSOR (IN ROOF CONSOLE) WHT/GRY WIRE WHT/PPL WIRE WHT/RED WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/RED WIRE YEL/WHT WIRE

AIR SUSPENSION MODULE (RIGHT SIDE OF LUGGAGE COMPT) AUDIO HEAD UNIT BLK WIRE CENTER CONSOLE SWITCH PACK CLIMATE CONTROL SEAT MODULE (UNDER DRIVER'S SEAT) COMPANION (BEHIND RIGHT END OF DASH) CONTINUOUSLY VARIABLE DAMPING MODULE (RIGHT SIDE OF LUGGAGE COMPT) DRIVER SEAT SWITCH PACK DRIVER SEAT SWITCH PACK (W/ HEAD RESTRAINT) ELECTROCHROMIC MIRROR GRY WIRE HS CAN HI HS CAN LO INTEGRATED CLIMATE CONTROL MODULE, SWITCH PACK KEYLESS VEHICLE MODULE LEFT BLIND SPOT MONITORING MODULE LEFT DYNAMIC BENDING LAMP MOTOR LEFT FRONT SEAT MODULE LEFT HEADLAMP LEFT REAR SEATS SWITCH PACK MS CAN-HI MS CAN-LO OCCUPANCY DETECTOR SENSOR (UNDER FRONT PASSENGER'S SEAT) PARKING AID MODULE (AT LEFT SIDE OF LUGGAGE COMPT) PARKING BRAKE MODULE (UNDER REAR OF VEHICLE) PASSENGER DOOR MODULE (IN FRONT PASSENGER'S DOOR) PASSENGER SEAT SWITCH PACK REAR AUTOMATIC TEMPERATURE CONTROL MODULE REAR CLIMATE CONTROL SWITCH PACK REAR DIFFERENTIAL CONTROL MODULE (BELOW LEFT REAR SEAT) RED WIRE RESTRAINTS CONTROL MODULE (UNDER CENTER CONSOLE) RIGHT BLIND SPOT MONITORING MODULE (BEHIND RIGHT SIDE OF REAR BUMPER) RIGHT DYNAMIC BENDING LAMP MOTOR RIGHT FRONT SEAT MODULE RIGHT HEADLAMP RIGHT REAR DOOR MODULE (IN REAR DOOR) RIGHT REAR SEATS SWITCH PACK SPEED CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT) W/ HEAD RESTRAINT W/ HEAD RESTRAINT W/O HEAD RESTRAINT W/ MEMORY W/O HEAD RESTRAINT W/O MEMORY WHT WIRE WHT/GRY WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/WHT WIRE
