Land Rover Range Rover L322 (2009-2012) shift command switch wiring diagram
This page shows the only wiring diagram for the component.shift command switch, which is found in the car Land Rover Range Rover L322 (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
shift command switch wiring diagram (1 of 1)
ABS MODULE
AFS CONTROL MODULE
AIR BAG DISABLE PASSENGER SWITCH
BLK WIRE
BRN WIRE
COOLANT PUMP
GRN WIRE
HEAVY DUTY HORN
IMMOBILIZER ANTENNA MODULE
INSTRUMENT CLUSTER
LEFT CUSHION SEAT HEATER
LEFT FRONT FOG LAMP
LEFT FRONT SEAT MODULE
LEFT FRONT TREAD PLATE ILLUMINATION
LEFT HEADLAMP
LEFT HORN
LEFT LUMBAR SWITCH
LEFT LUMBAR VALVE BLOCK
LEFT REAR CUSHION HEATER
LEFT REAR LUMBAR PUMP
LEFT SEAT BACKREST HEATER
MAGNETIC VALVE
PAD WEAR SENSOR
PARK LOCK SOLENOID
PASSENGER SEAT SWITCH PACK
PCB/PRND POSITION SENSOR
REAR BLOWER MOTOR CONTROL MODULE
REAR ENTERTAINMENT DOCKING STATION REMOTE CONTROL
REAR SEATS CLIMATE MODULE
RIGHT CUSHION SEAT HEATER
RIGHT FRONT FOG LAMP
RIGHT FRONT OUTER VENT ILLUMINATION
RIGHT FRONT SEAT MODULE
RIGHT FRONT TREAD PLATE ILLUMINATION
RIGHT HEADLAMP
RIGHT HORN
RIGHT LUMBAR SWITCH
RIGHT LUMBAR VALVE BLOCK
RIGHT REAR CUSHION HEATER
RIGHT REAR LUMBAR PUMP
RIGHT SEAT BACKREST HEATER
SHIFT COMMAND SWITCH
STEERING COLUMN SWITCH
W/ HEATED SEATS
W/O HEATED SEATS
WHT WIRE
WHT/BLK WIRE
WINDSCREEN WIPER MOTOR
YAW RATE SENSOR
Go to component -> Ground distribution circuit (4 of 4) -> SHIFT COMMAND SWITCH
