Land Rover Range Rover L322 (2005-2009) Touch screen interface circuit

ANTI-LOCK BRAKES SYSTEM AUDIO HEAD UNIT AUXILIARY JUNCTION BOX BLK WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/RED WIRE BRN WIRE CENTRAL JUNCTION BOX CLR COMPANION COMPUTER DATA LINES SYSTEM FRONT INTERIOR LAMP FUSE 43 FUSE LINK 49 GPS ANTENNA GRN WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES INFOTAINMENT RELAY INSTRUMENT CLUSTER MICROPHONE NAVIGATION SYSTEM MODULE NCA WIRE ORG/ WIRE REAR SEAT ENTERTAINMENT MODULE REAR VIEW CAMERA RED WIRE RED/GRN WIRE RED/YEL WIRE TOUCH SCREEN DISPLAY WHT WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/RED WIRE YEL/WHT WIRE
