Instrument illumination circuit for Land Rover Range Rover L322 (2005-2009)

AIR SUSPENSION RIDE HEIGHT SWITCH AUDIO UNIT BLK WIRE BRN WIRE BRN/BLK WIRE CENTER FASCIA SWITCH PACK CENTRAL JUNCTION BOX DRIVER'S DOOR MODULE DSC SWITCH FRONT INTERIOR LAMP FUSE 4 FUSE 45 FUSE 49 FUSE 51 FUSE 9 FUSE LINK 3 FUSE LINK 4 GRN WIRE GRN/GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN ON HOT IN ON OR ACC ILLUM INSTRUMENT CLUSTER LEFT FRONT DOOR HANDLE LED LEFT FRONT DOOR POCKET LED LEFT REAR DOOR HANDLE LED LEFT REAR WINDOW SWITCH LIGHTING CONTROL SWITCH LIGHTING SWITCH MODULE PDC SWITCH PPL/GRN WIRE PPL/YEL WIRE REAR AIR CONDITIONING SWITCH RED WIRE RED/GRN WIRE TAILGATE RELEASE SWITCH TO CENTRAL JUNCTION BOX (DIAGRAM 2 OF 2) TOUCH SCREEN DISPLAY WATERFALL LIGHTING LED YEL WIRE

ACCESS/ ANALOGUE CLOCK AUTOMATIC GEARBOX SELECTOR ILLUMI- NATION AUTOMATIC TEMPERATURE CONTROL MODULE BRN WIRE BRN/BLK WIRE CENTER CONSOLE SWITCH PACK CENTRAL JUNCTION BOX ELECTRIC PARK BRAKE SWITCH FROM FUSE 51 CENTRAL JUNCTION BOX (DIAGRAM 1 OF 2) GRY/BLU WIRE GRY/RED WIRE HAZARD WARNING, CDL MASTER SWITCH HOLD LEFT FRONT INNER VENT ILLUMI- NATION LEFT FRONT OUTER VENT ILLUMI- NATION LEFT REAR VENT ILLUMI- NATION LOWERING OFF ROAD PASSENGER DOOR MODULE RAISING REAR AIR CONDITIONING SWITCH PACK REAR INTERIOR LAMP RIGHT FRONT DOOR HANDLE LED RIGHT FRONT DOOR POCKET LED RIGHT FRONT INNER VENT ILLUMI- NATION RIGHT FRONT OUTER VENT ILLUMI- NATION RIGHT REAR DOOR HANDLE LED RIGHT REAR VENT ILLUMI- NATION RIGHT REAR WINDOW SWITCH ROOF OPENING PANEL CONTROL MODULE SPORT DISPLAY MANUAL ILLUMI- NATION STANDARD SUN ROOF SWITCH TEMPE- RATURE BLEND VENT ILLUMI- NATION TERRAIN OPTIMIZATION SWITCH TRANSMISSION HIGH-LOW SWITCH WATERFALL LAMPS LED YEL/GRY WIRE
