Land Rover Range Rover L322 (2002-2005) right folding mirror motor Wiring diagram
This page shows the only wiring diagram for the component.right folding mirror motor, which is found in the car Land Rover Range Rover L322 (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right folding mirror motor (1 of 1)
BLU WIRE
BLU/RED WIRE
BODY CONTROL UNIT
BRN WIRE
DRIVER'S DOOR MIRROR
DRIVER'S DOOR MODULE
FUSE 11
FUSE 24
GRN/BRN WIRE
HOT AT ALL TIMES
LEFT FOLDING MIRROR MOTOR
MICRO SWITCH
PASSENGER COMPARTMENT FUSE BOX
PASSENGER DOOR MIRROR
PASSENGER DOOR MODULE
RED/BLU WIRE
RED/PPL WIRE
RED/WHT WIRE
RIGHT FOLDING MIRROR MOTOR
WHT/YEL WIRE
Go to component -> Fold-back mirrors circuit -> RIGHT FOLDING MIRROR MOTOR
