Land Rover Range Rover L322 (2002-2005) right backrest heater Wiring diagrams

BRN WIRE FUSE 12 FUSE 52 GRN/PPL WIRE GRN/YEL WIRE HEVAC CONTROL MODULE HOT AT ALL TIMES LEFT BACKREST HEATER LEFT SEAT CUSHION HEATER LEFT SEAT HEATER SWITCH PASSENGER COMPARTMENT FUSE BOX RED/BLU WIRE RED/PPL WIRE RIGHT BACKREST HEATER RIGHT SEAT CUSHION HEATER RIGHT SEAT HEATER SWITCH WHT/BLU WIRE WHT/GRN WIRE

AIR BAG DCU AIR INJECTION PUMP RELAY AIR SUSPENSION ECU AIR SUSPENSION UNIT BATTERY BACKED UP ALARM SOUNDER BODY CONTROL UNIT (BCU) BRN WIRE BRN/BLK WIRE CAPACITOR ENGINE COMPARTMENT FUSE BOX FRONT ACCESSORY SOCKET FRONT CIGAR LIGHTER GLOVE BOX LAMP) HEVAC CONTROL MODULE IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 LEFT FRONT FOOTWELL LAMP LEFT LOWER CDL TAILGATE MOTOR LEFT REAR CUSHION HEATER LEFT REAR SIDE MARKER LAMP LEFT REVERSE LAMP LEFT SIDE AIR BAG SENSOR LEFT TAIL LAMP UNIT LIGHTING SWITCH MODULE NCA WIRE PASSENGER ANTI-TRAP SENSOR PASSENGER DOOR MODULE POWER WASH RELAY REAR BLOWER MOTOR CONTROL UNIT REAR CIGAR LIGHTER REAR HEVAC CONTROL UNIT RIGHT APPROACH LAMP RIGHT BACKREST HEATER RIGHT FRONT DOOR HANDLE LED RIGHT FRONT DOOR LOCK MOTOR RIGHT FRONT DOOR POCKET LED RIGHT FRONT DOOR SILL LAMP RIGHT FRONT PUDDLE LAMP RIGHT FRONT SCREEN ELEMENT RIGHT LOWER CDL TAILGATE MOTOR RIGHT REAR ANTI-TRAP SENSOR RIGHT REAR CENTRAL DOOR LOCKING MOTOR RIGHT REAR CUSHION HEATER RIGHT REAR DOOR HANDLE LED RIGHT REAR PUDDLE LAMP RIGHT REAR WINDOW SWITCH RIGHT REVERSE LAMP RIGHT SEAT CUSHION HEATER RIGHT SEAT SWITCH PACK RIGHT SIDE AIR BAG SENSOR SEAT OCCUPANCY MODULE STEERING COLUMN RELAY SUN ROOF ECU WINDSCREEN WIPER DELAY ECU WIPER BLADE HEATER YEL WIRE
