Rear seat entertainment circuit for Land Rover Range Rover III facelift (2005-2009)

AUDIO HEAD UNIT AUXILIARY JUNCTION BOX B/L DC SUPPLY B/L GND B/L SUPPLY BATT 12+ BLU WIRE BRN WIRE COMP VIDEO GND CVBS GND CVBS OUT FUSE 10 FUSE 11 FUSE 9 HOT AT ALL TIMES INFOTAINMENT RELAY IS-BUS FRAME- IS-BUS SIG- LEFT REAR SEAT ENTERTAINMENT SCREEN MOST IN MOST OUT NCA WIRE ORG/ WIRE POWER GND PPL/WHT WIRE REAR SEAT ENTERTAINMENT MODULE RED WIRE RED/BLU WIRE RIGHT REAR SEAT ENTERTAINMENT SCREEN TMC RECEIVER TOUCH SCREEN DISPLAY TV TUNER MODULE VIDEO COMP OUT

AUDIO GND AUDIO O/P LCH AUDIO O/P RCH AUDIO SHIELD GND AUX 1 AUDIO L- AUX 1 AUDIO R- AUX 1 VIDEO- AUX 2 AUDIO L- AUX 2 AUDIO R- AUX 2 VIDEO- AV INPUT PANEL BLK WIRE BLU WIRE BRN WIRE CENTRAL JUNCTION BOX DVD MULTI-CHANGER FUSE 49 GRN WIRE HEADPHONE UNIT HOT AT ALL TIMES LH AUDIO +VE LH AUDIO -VE GND NCA WIRE ORG/ WIRE POWER AMPLIFIER REAR SEAT ENTERTAINMENT MODULE RED WIRE RED/GRN WIRE REMOCON GND REMOCON SIG RH AUDIO -VE RH AUDIO -VE GND START UP SUB WOOFER MODULE VIDEO COMP OUTPUT VIDEO GND YEL WIRE
